IGBT Modules
Insulated-gate bipolar transistors (IGBTs) are three-terminal power semiconductor devices primarily used as electronic switches that combine high efficiency and fast switching. As modules, IGBTs are configured as asymmetrical bridges, boost, buck and brake choppers, full-bridge, three-level and three-phase inverters. Some have built-in NTC thermistors for temperature monitoring. IGBT modules are differentiated by max power, collector current, collector-emitter breakdown voltage and configuration.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
APT150GT120JR
|
Microsemi Corporation | IGBT 1200V 170A 830W SOT227 | 7 | $52.04 | |
FP35R12W2T4B11BOMA1
|
Infineon Technologies | IGBT MODULE 1200V 35A | 26 | $50.57 | |
|
FP50R06W2E3BOMA1
|
Infineon Technologies | IGBT MODULE 600V 450A | 15 | $48.57 | |
APT85GR120JD60
|
Microsemi Corporation | IGBT MODULE 1200V 116A ISOTOP | 40 | $39.71 | |
|
APT80GP60J
|
Microsemi Corporation | IGBT 600V 151A 462W SOT227 | 9 | $39.19 | |
|
APT200GN60JDQ4
|
Microsemi Corporation | IGBT 600V 283A 682W SOT227 | 43 | $39.09 | |
FP20R06W1E3BOMA1
|
Infineon Technologies | IGBT MODULE 600V 20A | 24 | $33.19 | |
|
APT60GA60JD60
|
Microsemi Corporation | IGBT 600V 112A 356W SOT-227 | 11 | $31.94 | |
|
FF600R12ME4CBOSA1
|
Infineon Technologies | IGBT MODULE 1200V 600A | 10 | $240.60 | |
BSM50GP120BOSA1
|
Infineon Technologies | IGBT MODULE 1200V 50A | 14 | $172.84 |
