IGBT Modules
Insulated-gate bipolar transistors (IGBTs) are three-terminal power semiconductor devices primarily used as electronic switches that combine high efficiency and fast switching. As modules, IGBTs are configured as asymmetrical bridges, boost, buck and brake choppers, full-bridge, three-level and three-phase inverters. Some have built-in NTC thermistors for temperature monitoring. IGBT modules are differentiated by max power, collector current, collector-emitter breakdown voltage and configuration.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
APTGF75DA60D1G
|
Microsemi Corporation | IGBT 600V 100A 355W D1 | 0 | $0.00 | |
|
APTGF75DA120T1G
|
Microsemi Corporation | IGBT 1200V 100A 500W SP1 | 0 | $0.00 | |
|
APTGF660U60D4G
|
Microsemi Corporation | IGBT 600V 860A 2800W D4 | 0 | $0.00 | |
|
APTGF530U120D4G
|
Microsemi Corporation | IGBT 1200V 700A 3900W D4 | 0 | $0.00 | |
APTGF50X60T3G
|
Microsemi Corporation | IGBT MODULE NPT 3PH BRIDGE SP3 | 0 | $0.00 | |
|
APTGF50TDU120PG
|
Microsemi Corporation | IGBT MODULE NPT TRPL DUAL SP6-P | 0 | $0.00 | |
|
APTGF50TA120PG
|
Microsemi Corporation | IGBT MODULE NPT TRPL PHASE SP6P | 0 | $0.00 | |
|
APTGF50H60T1G
|
Microsemi Corporation | IGBT MODULE NPT FULL BRIDGE SP1 | 0 | $0.00 | |
APTGF50H120TG
|
Microsemi Corporation | IGBT MODULE NPT FULL BRIDGE SP4 | 0 | $0.00 | |
|
APTGF50DU120TG
|
Microsemi Corporation | IGBT MODULE NPT DUAL SP4 | 0 | $0.00 |
