IGBT Modules
Insulated-gate bipolar transistors (IGBTs) are three-terminal power semiconductor devices primarily used as electronic switches that combine high efficiency and fast switching. As modules, IGBTs are configured as asymmetrical bridges, boost, buck and brake choppers, full-bridge, three-level and three-phase inverters. Some have built-in NTC thermistors for temperature monitoring. IGBT modules are differentiated by max power, collector current, collector-emitter breakdown voltage and configuration.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
APTCV60HM70BT3G
|
Microsemi Corporation | POWER MOD IGBT3 FULL BRIDGE SP3 | 0 | $0.00 | |
VS-CPV363M4KPBF
|
Vishay / Semiconductor - Diodes Division | MOD IGBT 3PHASE INV 600V SIP | 0 | $0.00 | |
APT70GR120J
|
Microsemi Corporation | IGBT 1200V 112A 543W SOT227 | 0 | $0.00 | |
|
APT50GR120JD30
|
Microsemi Corporation | IGBT 1200V 84A 417W SOT227 | 0 | $0.00 | |
CM200EXS-24S
|
Powerex, Inc. | IGBT 1200V 200A 1500W MODULE | 0 | $0.00 | |
|
CM150EXS-24S
|
Powerex, Inc. | IGBT 1200V 150A 1150W MODULE | 0 | $0.00 | |
CM600DY-24S
|
Powerex, Inc. | IGBT HALF BRIDGE 1200V 600A MOD | 0 | $0.00 | |
CM300DY-24S
|
Powerex, Inc. | IGBT HALF BRIDGE 1200V 300A MOD | 0 | $0.00 | |
|
QID4515001
|
Powerex, Inc. | MOD IGBT 150A 4500V DUAL | 0 | $0.00 | |
|
CM75TX-24S
|
Powerex, Inc. | IGBT MODULE 6-PAC 75A 1200V | 0 | $0.00 |
