Crystals
Crystal products are passive components most commonly used as time or frequency references in electronic systems. Consisting of a piezoelectric crystal that mechanically vibrates at a known frequency, their use requires provision of an external oscillator circuit with carefully designed capacitance, drive voltage, and series resistance characteristics, to generate a signal at the indicated crystal frequency that operates successfully over the operating temperature range, without damaging the crystal element. Active devices which integrate this additional necessary circuitry are considered oscillators and are catalogued separately.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
NX2520SA-25.000M-STD-CSW-5
|
NDK America, Inc. | CRYSTAL 25.0000MHZ 8PF SMD | 3000 | $0.41 | |
NX8045GB-8.000M-STD-CSJ-1
|
NDK America, Inc. | CRYSTAL 8.0000MHZ 8PF SMD | 9464 | $0.00 | |
7V-25.000MAAE-T
|
TXC Corporation | CRYSTAL 25.0000MHZ 12PF SMD | 9901 | $0.86 | |
ABM11W-16.0000MHZ-8-K1Z-T3
|
Abracon LLC. | CRYSTAL 16.0000MHZ 8PF SMD | 4105 | $0.00 | |
ABM3C-15.000MHZ-D4Y-T
|
Abracon LLC. | CRYSTAL 15.0000MHZ 18PF SMD | 2194 | $0.00 | |
416F26022IKR
|
CTS-Frequency Controls | CRYSTAL 26.000 MHZ 8PF SMT | 9000 | $0.48 | |
7M-13.560MAAJ-T
|
TXC Corporation | CRYSTAL 13.5600MHZ 18PF SMD | 3000 | $0.51 | |
|
7M-40.000MAAJ-T
|
TXC Corporation | CRYSTAL 40.0000MHZ 18PF SMD | 6188 | $0.00 | |
ABM7-19.6608MHZ-D2Y-T
|
Abracon LLC. | CRYSTAL 19.6608MHZ 18PF SMD | 7000 | $0.52 | |
|
7M-32.000MAHE-T
|
TXC Corporation | CRYSTAL 32.0000MHZ 12PF SMD | 8611 | $1.05 |
