Crystals
Crystal products are passive components most commonly used as time or frequency references in electronic systems. Consisting of a piezoelectric crystal that mechanically vibrates at a known frequency, their use requires provision of an external oscillator circuit with carefully designed capacitance, drive voltage, and series resistance characteristics, to generate a signal at the indicated crystal frequency that operates successfully over the operating temperature range, without damaging the crystal element. Active devices which integrate this additional necessary circuitry are considered oscillators and are catalogued separately.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
8Y-32.000MAAV-T
|
TXC Corporation | CRYSTAL 32.0000MHZ 8PF SMD | 6000 | $0.44 | |
7V-32.000MAAE-T
|
TXC Corporation | CRYSTAL 32.0000MHZ 12PF SMD | 8553 | $0.00 | |
NX3225SA-12MHZ-STD-CSR-3
|
NDK America, Inc. | CRYSTAL 12.0000MHZ 8PF SMD | 9000 | $0.45 | |
CS325S16000000ABJT
|
Citizen Finedevice Co., LTD. | CRYSTAL 16.0000MHZ 18PF SMD | 15370 | $0.00 | |
ABM3C-48.000MHZ-D4Y-T
|
Abracon LLC. | CRYSTAL 48.0000MHZ 18PF SMD | 8310 | $0.00 | |
AA-12.000MAGE-T
|
TXC Corporation | CRYSTAL 12.0000MHZ 12PF SMD | 3043 | $0.87 | |
|
NX3225SA-20.000000MHZ-B2
|
NDK America, Inc. | CRYSTAL 20.0000MHZ 7.2PF SMD | 12198 | $0.00 | |
016875
|
Crystek Corporation | CRYSTAL 9.84375MHZ SMD | 15925 | $0.00 | |
ABM8G-20.000MHZ-B4Y-T
|
Abracon LLC. | CRYSTAL 20.0000MHZ 10PF SMD | 2000 | $0.50 | |
AB-25.000MAGE-T
|
TXC Corporation | CRYSTAL 25.0000MHZ 12PF SMD | 5604 | $0.00 |
