IGBT Modules
Insulated-gate bipolar transistors (IGBTs) are three-terminal power semiconductor devices primarily used as electronic switches that combine high efficiency and fast switching. As modules, IGBTs are configured as asymmetrical bridges, boost, buck and brake choppers, full-bridge, three-level and three-phase inverters. Some have built-in NTC thermistors for temperature monitoring. IGBT modules are differentiated by max power, collector current, collector-emitter breakdown voltage and configuration.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
APT35GP120J
|
Microsemi Corporation | IGBT 1200V 64A 284W SOT227 | 2 | $38.62 | |
F3L50R06W1E3B11BOMA1
|
Infineon Technologies | IGBT MODULE VCES 600V 50A | 0 | $37.82 | |
|
IXGN400N60B3
|
IXYS | IGBT 600V 430A SOT-227 | 0 | $37.65 | |
|
APT100GT60JRDQ4
|
Microsemi Corporation | IGBT 600V 148A 500W SOT227 | 0 | $37.32 | |
|
MIXA20WB1200TML
|
IXYS | IGBT MODULE 1200V 20A HEX | 0 | $36.99 | |
APTGT100DA60T1G
|
Microsemi Corporation | IGBT BOOST CHOP 600V 150A SP1 | 0 | $36.93 | |
IXGN82N120B3H1
|
IXYS | IGBT 1200V 145A SOT-227 | 0 | $36.91 | |
|
IXGN82N120C3H1
|
IXYS | IGBT 1200V 58A GENX3 SOT-227B | 0 | $36.91 | |
|
FS35R12W1T4B11BOMA1
|
Infineon Technologies | MOD IGBT LOW PWR EASY1B-2 | 0 | $36.83 | |
|
IXXN200N60C3H1
|
IXYS | IGBT 600V 200A SOT-227 | 0 | $36.57 |
