IGBT Modules
Insulated-gate bipolar transistors (IGBTs) are three-terminal power semiconductor devices primarily used as electronic switches that combine high efficiency and fast switching. As modules, IGBTs are configured as asymmetrical bridges, boost, buck and brake choppers, full-bridge, three-level and three-phase inverters. Some have built-in NTC thermistors for temperature monitoring. IGBT modules are differentiated by max power, collector current, collector-emitter breakdown voltage and configuration.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
FS50R12W2T4BOMA1
|
Infineon Technologies | MOD IGBT LOW PWR EASY2B-1 | 0 | $48.03 | |
|
APTGT30X60T3G
|
Microsemi Corporation | IGBT MOD TRENCH 3PH BRIDGE SP3 | 0 | $48.02 | |
|
APTGT50H60T1G
|
Microsemi Corporation | IGBT MOD TRENCH FULL BRIDGE SP1 | 0 | $47.99 | |
|
MID100-12A3
|
IXYS | MOD IGBT RBSOA 1200V 135A Y4-M5 | 0 | $47.90 | |
|
MDI100-12A3
|
IXYS | IGBT NPT BUCK 1200V 135A Y4-M5 | 0 | $47.90 | |
|
F3L75R07W2E3B11BOMA1
|
Infineon Technologies | IGBT MODULE VCES 600V 75A | 0 | $47.78 | |
|
VWI15-12P1
|
IXYS | MODULE IGBT 18A 1200V ECO-PAC2 | 0 | $47.63 | |
|
DF100R07W1H5FPB54BPSA2
|
Infineon Technologies | LOW POWER EASY | 0 | $47.62 | |
APTGL60DDA120T3G
|
Microsemi Corporation | IGBT4 MODULE TRENCH 1200V SP3 | 0 | $47.17 | |
APTGT50A120T1G
|
Microsemi Corporation | IGBT MOD TRENCH PHASE LEG SP1 | 0 | $47.03 |
