Balun
A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
HHM1603A1
|
TDK Corporation | BALUN 2.3GHZ-2.7GHZ 50/100 4SMD | 8280 | $0.00 | |
ATB2012E-75011M-T000
|
TDK Corporation | BALUN 400MHZ-1.8GHZ 75/75 0805 | 1409 | $0.00 | |
458DB-1012=P3
|
Toko America Inc. | BALUN 50MHZ-400MHZ 5SMD | 1614 | $0.83 | |
B0809J50ATI
|
Anaren | BALUN 850MHZ-915MHZ 0805 | 3128 | $1.10 | |
|
B0922J7575A50HF
|
Anaren | BALUN 950MHZ-2.15GHZ 75/75 0805 | 3815 | $0.00 | |
5400BL14B100T
|
Johanson Technology Inc. | BALUN 4.9GHZ-5.87GHZ 50/100 0603 | 2215 | $0.00 | |
ATB3225-75011CT-T001
|
TDK Corporation | BALUN 5MHZ-200MHZ 1:1 1210 | 1000 | $0.95 | |
MABA-011085
|
M/A-Com Technology Solutions | BALUN 5 - 1225 MHZ 1:1 | 1665 | $0.00 | |
CX2047LNLT
|
Pulse Electronics Network | BALUN 500KHZ-300MHZ 50/50 5SMD | 1590 | $2.90 | |
|
CX2043LNLT
|
Pulse Electronics Network | BALUN 1MHZ-1GHZ 1.5:1 5SMD MODUL | 689 | $0.00 |
