Balun
A Balun is a device designed to connect two circuits by converting or unconverting balanced and unbalanced loads. The characteristics are frequency range, impedance -unbalanced/balanced, phase difference, insertion loss, and return loss. The frequency range is from 10kHz to 23.6GHz with an impedance from 1:1 to 100/100Ohm and a phase difference from -155° ±15° to 195°.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
HHM17152A1
|
TDK Corporation | BALUN 698MHZ-894MHZ 50/100 0603 | 6659 | $0.69 | |
BD2425NNRF
|
Anaren | BALUN 2.4GHZ-2.525GHZ 0404 | 5083 | $0.66 | |
HHM1524B4
|
TDK Corporation | BALUN 824MHZ-894MHZ 50/150 0805 | 2000 | $0.20 | |
2450BL14C200T
|
Johanson Technology Inc. | BALUN 2.4GHZ-2.5GHZ 50/200 0603 | 57815 | $0.00 | |
2345FB39A0050E
|
Johanson Technology Inc. | BALUN 2.3GHZ-2.39GHZ 50/50 1008 | 3000 | $1.49 | |
HHM1908A2
|
TDK Corporation | MULTILYER BALUN FOR 4900 - 5950M | 29350 | $0.00 | |
HHM15112A1
|
TDK Corporation | BALUN 900MHZ-2.2GHZ 75/100 0805 | 3565 | $0.65 | |
HHM1713E2
|
TDK Corporation | MULTILAYER BALUN FOR 2400 - 2500 | 7200 | $0.00 | |
ATB2012E-20011-T06
|
TDK Corporation | BALUN 13.56MHZ 20/20 0805 | 4000 | $0.26 | |
DLPF-GP-01D3
|
STMicroelectronics | BALUN 2.4-2.5GHZ 100/100 16SMD | 5000 | $0.58 |
