Full Half-Bridge Drivers
Devices in the bridge driver PMIC (Power Management Integrated Circuit) family incorporate two or more power transistors along with circuitry required to operate them as switches under the control of an external device. The transistors are typically configured internally in series-connected pairs known as half-bridges, such that the junction between any given pair can be connected to either of two power supply rails. They are commonly used to translate low-level signals provided by a control device such as a microcontroller into the higher power signals required to operate an actuator such as a stepper or brushless motor.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
STSPIN233
|
STMicroelectronics | LOW VOLTAGE TRIPLE HALF-BRIDGE M | 5256 | $0.00 | |
UC3717AN
|
Texas Instruments | IC BRIDGE DRIVER PAR 16DIP | 245 | $13.58 | |
BM6203FS-E2
|
ROHM Semiconductor | IC MOTOR DVR 3PH BRUSHLSS 54SSOP | 1000 | $6.44 | |
CSD95482RWJT
|
Texas Instruments | POWERSTAGE | 295 | $4.92 | |
UC2950TG3
|
Texas Instruments | IC HALF BRIDGE SWITCH 4A TO220-5 | 980 | $8.92 | |
HIP4086ABZT
|
Renesas Electronics America Inc. | IC DRIVER 3PHASE 80V 0.5A 24SOIC | 10000 | $3.30 | |
HIP4082IBZT
|
Renesas Electronics America Inc. | IC DRIVER FET H-BRDG 80V 16-SOIC | 0 | $1.98 | |
HIP4082IBZTS2366A
|
Renesas Electronics America Inc. | IC FET DVR H BRIDGE 16SOIC | 0 | $0.00 | |
|
HIP4086ABT
|
Renesas Electronics America Inc. | IC DRIVER MOSFET N-CH 3PH 24SOIC | 0 | $0.00 | |
|
HIP4083AB
|
Renesas Electronics America Inc. | IC DRIVER HISIDE N-CH 3PH 16SOIC | 0 | $0.00 |
