Crystals
Crystal products are passive components most commonly used as time or frequency references in electronic systems. Consisting of a piezoelectric crystal that mechanically vibrates at a known frequency, their use requires provision of an external oscillator circuit with carefully designed capacitance, drive voltage, and series resistance characteristics, to generate a signal at the indicated crystal frequency that operates successfully over the operating temperature range, without damaging the crystal element. Active devices which integrate this additional necessary circuitry are considered oscillators and are catalogued separately.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
ABM13W-52.0000MHZ-5-DH7G-T5
|
Abracon LLC. | CRYSTAL 52MHZ 5PF SMD | 0 | $1.68 | |
|
ABM13W-38.4000MHZ-5-DH7G-T5
|
Abracon LLC. | CRYSTAL 38.4MHZ 5PF SMD | 4990 | $0.00 | |
|
ABM13W-32.0000MHZ-5-NH7U-T5
|
Abracon LLC. | CRYSTAL 32MHZ 5PF SMD | 4888 | $3.15 | |
XM-1-010.0M
|
Connor-Winfield | CRYSTAL 10.0000MHZ 16PF SMD | 444 | $0.00 | |
NX2016SA-26M-STD-CZS-1
|
NDK America, Inc. | CRYSTAL 26.0000MHZ 8PF SMD | 206 | $0.81 | |
LFXTAL003210REEL
|
IQD Frequency Products | CRYSTAL 12.0MHZ 16PF SMD | 1251 | $0.00 | |
NX3225GA 24MHZ EXS00A-CG04818
|
NDK America, Inc. | CRYSTAL 24MHZ 8PF SMD | 0 | $0.29 | |
|
NX2016SA-24MHZ-EXS00A-CS07859
|
NDK America, Inc. | CRYSTAL 24MHZ 8PF SMD | 2462 | $0.00 | |
LFXTAL061647REEL
|
IQD Frequency Products | CRYSTAL 12.0MHZ 12PF SMD | 1925 | $0.00 | |
|
NX2016SA-24MHZ-EXS00A-CS08664
|
NDK America, Inc. | CRYSTAL 24MHZ 8PF SMD | 1906 | $0.64 |
