Crystals
Crystal products are passive components most commonly used as time or frequency references in electronic systems. Consisting of a piezoelectric crystal that mechanically vibrates at a known frequency, their use requires provision of an external oscillator circuit with carefully designed capacitance, drive voltage, and series resistance characteristics, to generate a signal at the indicated crystal frequency that operates successfully over the operating temperature range, without damaging the crystal element. Active devices which integrate this additional necessary circuitry are considered oscillators and are catalogued separately.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
ECS-120-20-33-TR
|
ECS Inc. | CRYSTAL 12.0000MHZ 20PF SMD | 5000 | $0.62 | |
ECS-250-20-33-TR
|
ECS Inc. | CRYSTAL 25.0000MHZ 20PF SMD | 10514 | $0.00 | |
ECS-100-18-30BQ-DS
|
ECS Inc. | CRYSTAL 10.0000MHZ 18PF SMD | 4272 | $1.20 | |
ECS-120-13-30B-AEM-TR
|
ECS Inc. | CRYSTAL 12MHZ 13PF SMD | 1890 | $0.00 | |
CX3225SB20000H0PSTC2
|
Kyocera International Inc. Electronic Components | CRYSTAL 20.0000MHZ 12PF SMD | 0 | $0.34 | |
|
ECS-147.4-10-30B-CKL-TR
|
ECS Inc. | CRYSTAL 14.7456MHZ 10PF SMD | 1430 | $0.00 | |
CX3225GB12000D0HPQCC
|
Kyocera International Inc. Electronic Components | CRYSTAL 12.0000MHZ 8PF SMD | 1895 | $0.66 | |
|
ECS-240-20-30B-AEN-TR
|
ECS Inc. | CRYSTAL 24MHZ 20PF SMD | 1018 | $0.00 | |
ECS-240-10-36-CKM-TR
|
ECS Inc. | CRYSTAL 24MHZ 10PF SMD | 1000 | $0.33 | |
|
ECS-400-10-36-CKY-TR
|
ECS Inc. | CRYSTAL 40MHZ 10PF SMD | 1983 | $0.00 |
