Shunts, Jumpers
Shunts or Jumpers are designed to connect two pin contacts for an electrical connection that are separated by a specific distance or pitch. The types are Closed Top/Grip, Insulated, Non-Insulated, and Open Top/Grip with a pitch range from 0.050” (1.27mm) to 1.00” (25.40mm) and the number of positions ranging from 1 (1 x 1) to 48 (1 x 24) or 4 (2 x 2) to 26 (2 x 13).
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
15-29-1026
|
Molex | CONN SHUNT OPEN TOP .100 GOLD | 3468 | $0.81 | |
15-29-1027
|
Molex | CONN SHUNT CLOSED TOP .100 GOLD | 40448 | $0.78 | |
142270-3
|
TE Connectivity AMP Connectors | CONNECTOR SHUNT 2 P | 1146 | $0.76 | |
MNT-103-BK-T
|
Samtec, Inc. | .100 C.L. SHUNT STRIP | 1056 | $0.71 | |
3360-1-14-15-00-00-08-0
|
Mill-Max Manufacturing Corp. | CIRCUIT PIN JUMPER .025"D .200"L | 3646 | $0.66 | |
ML-100
|
Aries Electronics | CONN MINI LINK JUMPER | 1669 | $0.64 | |
A3-SP(A)
|
Hirose Electric Co Ltd | CONN SHUNT F 2 POS 2MM ST | 5810 | $0.51 | |
71363-202LF
|
Amphenol ICC (FCI) | CONN SHUNT 2POS .100 HIBOX 30AU | 6162 | $0.43 | |
86730-301LF
|
Amphenol ICC (FCI) | MINITEK JUMPER | 9166 | $0.40 | |
|
SNT-100-YW-G
|
Samtec, Inc. | SHUNT & JUMPERS | 2767 | $0.36 |
