RF Directional Coupler
RF Directional Couplers are designed to couple a specific amount of electromagnetic power in a transmission line to a secondary line enabling the signal to be used in another circuit. The coupler types are Coupler-with Filter, Dual Band-Dual Path, and Standard with frequencies ranging from DC to 40 GHz. The coupling factor ranges from -20 dB to 49 dB with applications being AGSM, AMPS, CDMA, Cellular, DCS, DECT, E-GSM, General Purpose, GSM, LTE, Military, PCN, PCS, PDC, PHP, S-Band Radar, Telecom, W-CDMA, Wireless LAN, WLAN, and X-Band Radar.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
CP0603A2422DWTR
|
AVX Corporation | RF DIR COUPLER 2.422GHZ 0603 | 0 | $0.00 | |
|
CP0603A1950LLTR
|
AVX Corporation | RF DIR COUPLER 1.95GHZ 0603 | 0 | $0.00 | |
|
CP0603B1950CW
|
AVX Corporation | RF DIR COUPLER 1.95GHZ 0603 | 0 | $0.00 | |
|
CP0603B1950AW
|
AVX Corporation | RF DIR COUPLER 1.95GHZ 0603 | 0 | $0.00 | |
|
CP0603A1950DW
|
AVX Corporation | RF DIR COUPLER 1.95GHZ 0603 | 0 | $0.00 | |
|
CP0603A1950CW
|
AVX Corporation | RF DIR COUPLER 1.95GHZ 0603 | 0 | $0.00 | |
|
CP0603A1950BW
|
AVX Corporation | RF DIR COUPLER 1.95GHZ 0603 | 0 | $0.00 | |
|
CP0603A1950AW
|
AVX Corporation | RF DIR COUPLER 1.95GHZ 0603 | 0 | $0.00 | |
EHF-FD1729
|
Panasonic Electronic Components | RF DIR COUPLR 1.71-1.785GHZ 0805 | 0 | $0.00 | |
|
EHF-FD1728
|
Panasonic Electronic Components | RF DIR COUPLER 880-915MHZ 0805 | 0 | $0.00 |
