Full Half-Bridge Drivers
Devices in the bridge driver PMIC (Power Management Integrated Circuit) family incorporate two or more power transistors along with circuitry required to operate them as switches under the control of an external device. The transistors are typically configured internally in series-connected pairs known as half-bridges, such that the junction between any given pair can be connected to either of two power supply rails. They are commonly used to translate low-level signals provided by a control device such as a microcontroller into the higher power signals required to operate an actuator such as a stepper or brushless motor.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
AP1023AEN
|
AKM Semiconductor, Inc. | IC MOTOR DRIVER 7V 24QFN | 990 | $0.00 | |
STK581U3C2D-E
|
ON Semiconductor | IC MOTOR DRIVER 22SIP | 14 | $27.02 | |
LCS701HG
|
Power Integrations | IC LLC CTRL MFET 170W ESIP16C | 69 | $4.66 | |
STK534U363C-E
|
ON Semiconductor | 3 PHASE INVERTER IPM | 44 | $15.75 | |
CSD95377Q4MT
|
Texas Instruments | IC HALF-BRIDGE DRIVER PWM 8VSON | 296 | $0.00 | |
STK57FU394AG-E
|
ON Semiconductor | 2-IN-1 PFC AND INVERTER IPM | 80 | $15.75 | |
STK544UC62K-E
|
ON Semiconductor | IC BRIDGE DRIVER PAR 23SIP | 54 | $13.65 | |
LCS708HG
|
Power Integrations | IC LLC CTRL MFET 440W ESIP16C | 41 | $9.74 | |
|
CSD97395Q4MT
|
Texas Instruments | IC SYNC BUCK NEXFET 8VSON | 996 | $0.00 | |
DRV8332HDDV
|
Texas Instruments | IC MOTOR DRIVER 44HTSSOP | 7 | $246.02 |
