Gates and Inverters - Multi-Function, Configurable
Products in the configurable logic gate family perform elementary logic operations on individual logic signals in a fashion similar to standard logic gates, but without the limitation of being constrained to one specific function such as AND, NAND, etc. They are commonly implemented using a small number of logic gates internally, selected and interconnected to allow the overall logic function that is realized to be configured by the choice of which among several inputs the operating data is applied to, and the logic state to which any unused inputs are driven.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
74LVC1G99GF,115
|
Nexperia USA Inc. | IC GATE MUTLIFUNCT 3ST 8XSON | 7364 | $0.00 | |
74AUP1G98GW,125
|
Nexperia USA Inc. | IC GATE CONFIG MULT FUNCT 6TSSOP | 4120 | $0.00 | |
74LVC1G98FZ4-7
|
Diodes Incorporated | IC LOGIC GATE/INVERTER | 5710 | $0.00 | |
HMC722LP3E
|
Analog Devices, Inc. | IC AND/NAND/OR/NOR GATE 16SMT | 41 | $83.60 | |
|
HMC721LP3E
|
Analog Devices, Inc. | IC XOR/XNOR GATE 16SMT | 49 | $83.60 | |
SY58051AUMG
|
Microchip Technology | IC GATE CML | 320 | $12.54 | |
MC100EP01DG
|
ON Semiconductor | IC GATE OR/NOR ECL 4INPUT 8SOIC | 182 | $7.74 | |
|
MC100EP08DG
|
ON Semiconductor | IC GATE XOR/XNOR ECL 2INP 8SOIC | 190 | $7.74 | |
|
MC100EL05DG
|
ON Semiconductor | IC GATE AND/NAND ECL 2INP 8SOIC | 132 | $5.96 | |
|
MC100EL01DG
|
ON Semiconductor | IC GATE OR/NOR ECL 4INPUT 8SOIC | 146 | $5.96 |
