Crystals
Crystal products are passive components most commonly used as time or frequency references in electronic systems. Consisting of a piezoelectric crystal that mechanically vibrates at a known frequency, their use requires provision of an external oscillator circuit with carefully designed capacitance, drive voltage, and series resistance characteristics, to generate a signal at the indicated crystal frequency that operates successfully over the operating temperature range, without damaging the crystal element. Active devices which integrate this additional necessary circuitry are considered oscillators and are catalogued separately.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
AB-10.000MALE-T
|
TXC Corporation | CRYSTAL 10.0000MHZ 12PF SMD | 410 | $0.00 | |
CX3225GA30000D0PTVCC
|
Kyocera International Inc. Electronic Components | CRYSTAL 30.0000MHZ 8PF SMD | 969 | $0.97 | |
ABMM1-25.000MHZ-R40-D2X-T
|
Abracon LLC. | CRYSTAL 25.000MHZ 18PF SMD | 619 | $0.00 | |
ABMM-12.000MHZ-N2-T
|
Abracon LLC. | CRYSTAL 12.000MHZ 18PF SMD | 793 | $0.00 | |
405I35E25M00000
|
CTS-Frequency Controls | CRYSTAL 25.0000MHZ 20PF SMD | 0 | $0.53 | |
|
405C35B20M00000
|
CTS-Frequency Controls | CRYSTAL 20.0000MHZ 13PF SMD | 685 | $0.00 | |
|
405I35D48M00000
|
CTS-Frequency Controls | CRYSTAL 48.0000MHZ 18PF SMD | 244 | $0.00 | |
ECS-245.7-20-5PVX
|
ECS Inc. | CRYSTAL 24.5760MHZ 20PF SMD | 1000 | $1.02 | |
|
ECS-240-20-5PVX
|
ECS Inc. | CRYSTAL 24.0000MHZ 20PF SMD | 0 | $0.00 | |
|
405C35B16M00000
|
CTS-Frequency Controls | CRYSTAL 16.0000MHZ 13PF SMD | 0 | $0.55 |
