Shunts, Jumpers
Shunts or Jumpers are designed to connect two pin contacts for an electrical connection that are separated by a specific distance or pitch. The types are Closed Top/Grip, Insulated, Non-Insulated, and Open Top/Grip with a pitch range from 0.050” (1.27mm) to 1.00” (25.40mm) and the number of positions ranging from 1 (1 x 1) to 48 (1 x 24) or 4 (2 x 2) to 26 (2 x 13).
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
XJ8A-0211
|
Omron Electronics Inc-EMC Div | CONNECTOR | 141 | $0.31 | |
881545-5
|
TE Connectivity AMP Connectors | AMP SHUNT ASS'Y | 533 | $0.31 | |
HMSC-G
|
Adam Tech | SHUNT 1.27MM PITCH | 616 | $0.15 | |
531230-1
|
TE Connectivity AMP Connectors | SHUNT .200 C/L LP 2 POS SN | 1467 | $0.74 | |
SNT-100-YW-T
|
Samtec, Inc. | SHUNT JUMPERS | 185 | $0.24 | |
60910813421
|
Wurth Electronics Inc. | WR-PHD_2.54MM_JUMPER_BLACK W/ TE | 1885 | $0.74 | |
62200213421
|
Wurth Electronics Inc. | WR-PHD_1.27MM_JUMPER_BLACK_GOLD | 1710 | $0.62 | |
622002115121
|
Wurth Electronics Inc. | WR-PHD_1.27MM_JUMPER_BLACK W/ PU | 1875 | $0.62 | |
60910613421
|
Wurth Electronics Inc. | WR-PHD_2.54MM_JUMPER_BLACK W/ TE | 1999 | $0.59 | |
60910313421
|
Wurth Electronics Inc. | WR-PHD_2.54MM_JUMPER_BLACK W/ TE | 1399 | $0.44 |
