Magnetic, Reed Switches
Magnetic reed switches are devices consisting of a pair of ferromagnetic flexible metal reed contacts in a hermetically sealed glass, magneshere, or other molded body and are operated by an applied magnetic field. The contacts are normally open, closing when a magnetic field is present, or closed and open when a magnetic field is applied. The switch may be actuated by an electromagnetic coil or permanent magnet placed near the switch. When the magnetic field is removed, the reeds return to their original position. Contact forms include SPDT and SPST.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
PMC-1401S1520
|
PIC GmbH | STANDARD SMD REED SWITCH | 4865 | $0.00 | |
|
PMC-1401S2025
|
PIC GmbH | STANDARD SMD REED SWITCH | 4962 | $0.00 | |
MK23-66-B-2
|
Standex-Meder Electronics | SWITCH REED SPST-NO 500MA 200V | 2451 | $0.00 | |
59166-1-U-00-D
|
Littelfuse Inc. | SWITCH REED SPST-NO 350MA 140V | 1203 | $0.00 | |
|
59166-1-T-00-D
|
Littelfuse Inc. | SWITCH REED SPST-NO 350MA 140V | 1204 | $0.00 | |
PMC-08222025
|
PIC GmbH | STANDARD FORM C SWITCH | 200 | $12.95 | |
|
PMC-08221520
|
PIC GmbH | STANDARD FORM C SWITCH | 200 | $12.95 | |
PMC-1496S2530
|
PIC GmbH | STANDARD FORM C REED SWITCH | 391 | $6.10 | |
|
PMC-1496S2025
|
PIC GmbH | STANDARD FORM C REED SWITCH | 436 | $6.10 | |
|
PMC-1496S1520
|
PIC GmbH | STANDARD FORM C REED SWITCH | 482 | $6.10 |
