RF Mixers
RF mixers, or frequency mixers, are devices with three ports that are used to change the frequency of the two input signals. RF mixers are passive or active devices used for down converting or up converting signals. The characteristics are RF type, frequency, number of mixers, gain, noise figure, secondary attributes, current, and voltage. The frequency range is from 0 to 90 GHz with the number of mixers being 1, 2, 3, or 4.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
LTC5569IUF#PBF
|
Linear Technology / Analog Devices | IC MIXER 300MHZ-4GHZ DWN 16QFN | 94 | $16.48 | |
|
LT5520EUF#PBF
|
Linear Technology / Analog Devices | IC MIXER 1.3-2.3GHZ UPCONV 16QFN | 38 | $10.05 | |
MAX2682EUT+
|
Maxim Integrated | IC MXR 400MHZ-2.5GHZ DWN SOT23-6 | 186 | $2.51 | |
DB0440LW1
|
L3 Narda-MITEQ | BROADBAND DOUBLE BALANCED | 12 | $2593.34 | |
SBE0440LW1
|
L3 Narda-MITEQ | BROADBAND EVEN HARMONIC 1/2 LO | 3 | $2552.70 | |
|
M2640W1
|
L3 Narda-MITEQ | WIDE IF BANDWIDTH | 2 | $2268.22 | |
|
TB0440LW1
|
L3 Narda-MITEQ | BROADBAND WIDE IF TRIPLE BALANCE | 13 | $2040.89 | |
HMC815BLC5
|
Analog Devices, Inc. | MIXER, UPCONVERTER | 7 | $66.72 | |
HMC260ALC3B
|
Analog Devices, Inc. | IC MIXER FUNDAMENTAL 12SMD | 13 | $64.16 | |
|
HMC329ALC3B
|
Analog Devices, Inc. | IC MIXER MIXER 24-32GHZ 12SMD | 9 | $58.76 |
