Scale Dials
Scale Dials are a removable device with a face that is marked in predefined units to indicate the degree that a shaft has been turned. The knobs have a shaft size of 0.125” (3.18 mm), 0.236” (6.00 mm), or 0.250” (6.35 mm) with the number of turns being 1, 10, 11, 15, 20, 21, 30, or 100.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
H-22-3A
|
Bourns, Inc. | DIAL SCALE 15 TURN CONCENTRIC | 0 | $10.04 | |
H-516-3A
|
Bourns, Inc. | HARDWARE | 0 | $7.06 | |
P0400-86
|
Littelfuse Inc. | FACE PLATE 0.1 TO 10 MIN.REV.G | 0 | $4.82 | |
|
P0400-83
|
Littelfuse Inc. | FACE PLATE 1-60 SEC. REV. H | 0 | $4.82 | |
|
P0400-82
|
Littelfuse Inc. | FACE PLATE 0.1-10 SEC. REV. H | 0 | $4.82 | |
|
P0400-27
|
Littelfuse Inc. | FACE PLATE 0-10 DIAL REV A | 0 | $2.91 | |
|
P0400-17
|
Littelfuse Inc. | FACE PLATE 1-30 SEC. REV. E | 0 | $2.11 | |
H-23-6M
|
Bourns, Inc. | DIAL SCALE 15 TURN CONCENTRIC | 21 | $12.28 | |
|
H-22-6M
|
Bourns, Inc. | DIAL SCALE 15 TURN CONCENTRIC | 16 | $12.28 | |
H-516-6M
|
Bourns, Inc. | DIAL COUNTING 0-15 TURNS | 2 | $6.38 |
