Buffers, Drivers, Receivers, Transceivers
Logic buffers, drivers, receivers and transceivers allow isolated access to logic signals from one circuit for use in another circuit. Buffers pass their input signal, either unchanged or inverted, to their output and may be used to clean up a weak signal or drive a load. In a boolean logic simulator, a buffer is mainly used to increase propagation delay. Logic receivers and transceivers allow isolated communication between data buses.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
74LVC1G126GW-Q100H
|
Nexperia USA Inc. | IC BUF NON-INVERT 5.5V 5TSSOP | 5866 | $0.00 | |
74VHC9125FT
|
Toshiba Semiconductor and Storage | X34 PB-F UNIVERSAL SCHMITT BUFFE | 4963 | $0.48 | |
74LVC1G07QSE-7
|
Diodes Incorporated | IC LOGIC LVC 1 GATE SOT353 | 3000 | $0.09 | |
SN74LVC1G34DBVRE4
|
Texas Instruments | IC BUF NON-INVERT 5.5V SOT23-5 | 6000 | $0.10 | |
74AUP1G125GM-Q100X
|
Nexperia USA Inc. | SINGLE BUFFER/LINE DRIVER (3-STA | 10000 | $0.00 | |
74AUP1T50GXH
|
Nexperia USA Inc. | IC BUF NON-INVERT 3.6V 5X2SON | 10000 | $0.12 | |
74AUP1G125GS-Q100H
|
Nexperia USA Inc. | SINGLE BUFFER/LINE DRIVER (3-STA | 10000 | $0.13 | |
MC74VHC125DR2G
|
ON Semiconductor | IC BUF NON-INVERT 5.5V 14SOIC | 2500 | $0.15 | |
|
74LVC1G34GM,115
|
Nexperia USA Inc. | IC BUFFER NON-INVERT 5.5V 6XSON | 5000 | $0.00 | |
MC74HC245ADTR2G
|
ON Semiconductor | IC TXRX NON-INVERT 6V 20TSSOP | 5000 | $0.16 |
