Wireless Charging Coils
Wireless charging coils generate an alternating electromagnetic field used to inductively transfer energy to other coils positioned parallel and in close proximity. The energy is used to charge batteries or run the device receiving the energy. The coils may be designed as receivers, transmitters or dual purpose having single or multiple coils and multiple layers of windings. They are rated by their inductance, self resonant frequency, saturation current and Q factor at a given frequency.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
WT505090-10F2-LP-G
|
TDK Corporation | TX 1 COIL, 1 LYR 6.3UH | 158 | $9.35 | |
WT505090-10F2-LP-G1
|
TDK Corporation | TX 1 COIL, 1 LYR 6.3UH | 159 | $9.35 | |
WR444025-17M6-G
|
TDK Corporation | RX 1 COIL, 1 LYR 16.7UH | 412 | $9.33 | |
WR383245-17F5-G
|
TDK Corporation | RX 1 COIL, 1 LYR 13.9UH | 104 | $7.76 | |
WR555540-16K2-FS2
|
TDK Corporation | RX 1 COIL 2 LYR 15.8UH | 165 | $7.76 | |
WT202030-16M8-G
|
TDK Corporation | TX 1 COIL, 1 LYR 6.2UH | 470 | $7.54 | |
WR424245-13K2-G
|
TDK Corporation | RX 1 COIL, 1 LYR 11.9UH | 197 | $6.46 | |
WR483265-13F5-G
|
TDK Corporation | RX 1 COIL, 1 LYR 10.1UH | 192 | $5.72 | |
760308101304
|
Wurth Electronics Inc. | TX 1 COIL 1 LAYER 6.3UH 6A | 109 | $17.60 | |
760308102306
|
Wurth Electronics Inc. | WE-WPCC WIRELESS POWER CHARGING | 185 | $17.00 |
