PC Pin, Single Post Connectors
PC pin terminals or single post connectors are male gendered, single conductor devices, typically used on circuit boards. They are defined by the terminal type (double end, flanged, pc pin, single post), their terminal style (double end, flanged, pin retention, single end, smooth, wire), and their pin diameter or mounting hole diameter. Other parameters include overall length, mounting type (board edge, free-hanging, press fit, surface mount, through-hole), termination, etc.
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
H2087-01
|
Harwin Inc. | CONN PC PIN TIN | 3815 | $0.38 | |
H2105-01
|
Harwin Inc. | CONN PC PIN CIRC 0.032DIA TIN | 3878 | $0.24 | |
3117-1-00-21-00-00-08-0
|
Mill-Max Manufacturing Corp. | CONN PC PIN CIRC 0.024DIA GOLD | 2572 | $0.23 | |
3117-3-00-15-00-00-08-0
|
Mill-Max Manufacturing Corp. | CONN PC PIN CIRC 0.024DIA GOLD | 1688 | $0.20 | |
11158
|
Keystone Electronics | CONN PC PIN CIRC 0.040DIA TIN | 2416 | $1.38 | |
3601-3-07-21-00-00-08-0
|
Mill-Max Manufacturing Corp. | CONN PC PIN CIRC 0.080DIA GOLD | 1024 | $1.06 | |
3580-2-00-15-00-00-03-0
|
Mill-Max Manufacturing Corp. | .080" DIAMETER STRAIGHT PINS | 10193 | $0.75 | |
5920-0-00-15-00-00-03-0
|
Mill-Max Manufacturing Corp. | CONN PC PIN 0.080DIA GOLD | 1094 | $0.63 | |
3914-0-01-15-00-00-08-0
|
Mill-Max Manufacturing Corp. | CONN PC PIN CIRC 0.077DIA GOLD | 1244 | $0.57 | |
4288-0-00-15-00-00-33-0
|
Mill-Max Manufacturing Corp. | CONN PC PIN CIRC 0.018DIA GOLD | 3212 | $0.57 |
