Shunts, Jumpers
Shunts or Jumpers are designed to connect two pin contacts for an electrical connection that are separated by a specific distance or pitch. The types are Closed Top/Grip, Insulated, Non-Insulated, and Open Top/Grip with a pitch range from 0.050” (1.27mm) to 1.00” (25.40mm) and the number of positions ranging from 1 (1 x 1) to 48 (1 x 24) or 4 (2 x 2) to 26 (2 x 13).
| Part Number | Manufacturer | Description | Quantity | Price | Option |
|---|---|---|---|---|---|
5100TR
|
Keystone Electronics | COMPACT SMT JUMPER | 48516 | $0.00 | |
68786-102LF
|
Amphenol ICC (FCI) | CONN SHUNT 2POS .100 LOPRO GOLD | 11301 | $0.20 | |
M7582-05
|
Harwin Inc. | JUMPER SKT OPEN TOP BLACK | 50065 | $0.19 | |
2-881545-2
|
TE Connectivity AMP Connectors | CONN POST SHUNT NOVO 2POS | 138354 | $0.19 | |
382811-6
|
TE Connectivity AMP Connectors | CONN SHUNT 2POS OPEN 2.54MM | 89657 | $0.16 | |
382811-8
|
TE Connectivity AMP Connectors | CONN SHUNT 2POS OPEN 2.54MM | 33980 | $0.17 | |
5104TR
|
Keystone Electronics | MINIATURE SMT JUMPER | 48869 | $0.00 | |
SPN02SYBN-RC
|
Sullins Connector Solutions | CONN SHUNT 2MM OPEN TOP 2PS GOLD | 71417 | $0.13 | |
S1911-46R
|
Harwin Inc. | JUMPER TIN SMD | 40715 | $0.00 | |
NPC02SXON-RC
|
Sullins Connector Solutions | CONN JUMPER SHORTING .100" GOLD | 123018 | $0.11 |
